NC Battery Controller

Product information
Digital voltmeter with high-speed measuring cycle and clearly visible multi-colour LED display, for monitoring the state of NiCd batteries installed in the model. The display range can be programmed to the required values using the integral micro-switches. The programmable nature of the battery controller makes it a useful asset in all branches of modelling.
Specification
Operating voltage 4,8 … 8,4 V Measurement range 4 NC 4,2 … 8,4 V 5 NC 5,25 … 6,35 V 6 NC 6,3 … 7,65 V 7 NC 7,35 … 8,95 V 8 NC – 10-LED scale 3 x red/1 x yellow/6 x green Current drain approx. max. 30 mA Dimensions approx. 39 x 1 x 8 mm Weight approx. 6 g
